The High Lifter Honda Pioneer 1000 Riser Snorkel Kit, part SNORK-H1000P-2, is designed for the select Pioneer 1000 and Pioneer 1000-5 models listed below. It uses application-specific molded high-temperature silicone hoses and 2-inch riser caps to help supply clean, dry air to the engine and components requiring venting.
Installation requires cutting or trimming some plastic. Check your exact model, trim and year before ordering; compatibility varies by trim.
Features and benefits
- Custom-molded high-temperature silicone hoses designed for application-specific routing and reliable connections.
- Compatible with factory cab enclosure and back-glass applications.
- Carefully positioned risers designed to minimize obstruction of rear visibility.
- Powder-coated riser bracket keeps risers aligned and evenly spaced.
- Rubber grommets hold riser tubes in place and help prevent rattles.
- 2-inch High Lifter riser caps.
- Bellows accommodate differential and transmission air expansion and contraction without long vent lines that can plug with mud or pull loose.
Kit details and installation
- Brand: High Lifter
- Part number: SNORK-H1000P-2
- Product: Riser snorkel kit
- Installation: Cutting or trimming plastic required
- Mounting hardware and step-by-step instructions with detailed photos are included.
Kit contents vary by application; not every component described across the snorkel range is included in every kit. Review the application-specific instructions before installation.
View High Lifter SNORK-H1000P-2 installation instructions
Honda Pioneer fitment
- Pioneer 1000: 2016–2023
- Pioneer 1000 EPS: 2017–2019
- Pioneer 1000 LE: 2017–2019 and 2021
- Pioneer 1000 Deluxe: 2020–2022
- Pioneer 1000 Forest: 2022
- Pioneer 1000-5: 2016–2023
- Pioneer 1000-5 Deluxe: 2017–2022
- Pioneer 1000-5 LE: 2017–2021
- Pioneer 1000-5 Forest: 2022
Special/Limited Edition warning: The Honda Pioneer 1000 Special and 1000 Limited Edition lack the dash compartment used to attach the cup-holder relocation bracket. You will lose use of that bracket and the factory cup holder.
Important water-depth guidance
A snorkel kit provides an additional margin of protection if the vehicle inadvertently enters water deeper than the original air intakes can tolerate. It does not make the vehicle waterproof or mean it should exceed the original equipment manufacturer's maximum rated water depth. A snorkel is only one consideration when operating around water; follow your vehicle manufacturer's limits.
Frequently asked questions
Does this snorkel kit fit every 2016–2023 Honda Pioneer 1000?
No. Fitment is model-, trim- and year-specific. Match your vehicle to the list above, including the separate LE, Deluxe, EPS and Forest year ranges.
Does installation require cutting?
Yes. Some plastic must be cut or trimmed to install this kit. Review the SNORK-H1000P-2 instructions before starting.
Will it work with a factory cab enclosure and back glass?
The kit is listed as compatible with factory cab enclosure and back-glass applications.
Will I keep my factory cup holder?
The Pioneer 1000 Special and 1000 Limited Edition lack the mounting compartment for the cup-holder relocation bracket. On these models, you lose use of the bracket and factory cup holder.
Can I drive deeper than Honda's rated water depth?
No. Installing this snorkel kit is not permission to exceed the vehicle manufacturer's rated water-depth limit and does not waterproof the vehicle.
What is the part number?
The High Lifter part number for this kit is SNORK-H1000P-2.
